Name: Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer
SKU: 1005004623250799
Price: 18.52 GBP
Availability: InStock

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer - Image 2

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer - Image 3

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer - Image 4

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer - Image 5

Tools

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 TNM5000 RT809H Programmer

£18.52

Model Number: RT809H programmer ISP Application: Computer Type: Logic ICs Brand Name: XRIICHA Origin: Mainland China Condition: New Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 ，TNM5000，RT809H Programmer The PCB end of the adapter is composed of 48 pins, dual in line layout. Only the last 5 pins of each column of pins is used. So, it is […]

978 in stock

Estimated shipping to United Kingdom (UK):

SKU: 1005004623250799

Tags: adapter

Model Number: RT809H programmer ISP
Application: Computer
Type: Logic ICs
Brand Name: XRIICHA
Origin: Mainland China
Condition: New

Multipurpose ISP-Board-DuPont Adapter ISP-Header for XELTEK Superpro 610P 611S 6100N 7500 ，TNM5000，RT809H Programmer

The PCB end of the adapter is composed of 48 pins, dual in line layout. Only the last 5 pins of each column of pins is used. So, it is just a 10 pin header.

Here is the pin mapping layout:

Pin#1 –> Brown

Pin#2 –> Orange

Pin#3 –> Green

Pin#4 –> Purple

Pin#5 –> White

Pin#6 –> Black

Pin#7 –> Grey

Pin#8 –> Blue

Pin#9 –> Yellow

Pin#10 –>Red
